TECHNICAL SPECIFICATIONS
Speaker (front)
1” pure diamond
3” pure beryllium
7” pure ceramic
2 x 8” aluminium sandwich
Speaker (back)
2 x 10″ Passive Aluminium sandwich
Frequency range
23-40000 Hz +-2dB
Power rating
300 W
Sensitivity
88 dB / 2.83 V
Impedance
4 ohms (2.7 Ohms min)
Type
4-way
Crossover frequency
First order: 200, 800, 6000 Hz
Terminals
WBT Nextgen Bi-wire
Internal wiring
Jorma (optional Statement)
Cabinet
25-40 mm fibreboard laminate cabinet in Piano Black; tops and bottoms in solid wood or lacquered in different colours; advanced damping mat.
Stands
Mirror polished stainless steel with Marten Isolators
Dimensions W x H x D
33.5 x 126 x 46 cm
(13.2" x 49.6" x 18.1")
Net weight
95 kg (211 lbs)
