TECHNICAL SPECIFICATIONS
Speaker (front)
1 x 0.75″ Pure Diamond
1 x 2″ Pure Diamond
1 x 7″ Pure Ceramic
4 x 8″ Aluminium sandwich
Speaker (back)
4 x 10″ Passive Aluminium sandwich
Frequency range
22-100000 Hz +-2dB
Power rating
450 W
Sensitivity
89 dB / 1 m / 2.83V
Impedance
6 ohm (3.1 Ohm min)
Type
4-way
Crossover frequency
First order: 350, 3800 & 8000 Hz
Terminals
WBT Nextgen Bi-wire
Internal wiring
Jorma Design (optional Statement)
Cabinet
25-42 mm fibre laminate Piano Black, with Solid Wood top and bottom
Stands
Polished stainless steel with
Marten Isolators
Dimensions W x H x D
33.5 x 173 x 54 cm
(13.2 x 68.1 x 21.3")
Net weight
130 Kg (288 lbs)
